Electrical data



	Nominal wattage	30W
	Rated input voltage	240Vac
	Operating voltage range	100-300Vac
	Power factor	≥0.95
	ITHD	<10%
	Input frequency	50Hz
	Hi Pot Protection	1.5KVac
	Driver Efficiency	≥87%
	EMI/EMC(As Per CISPR15)	Pass
	Surge Protection	4.2 KV
	Dimming	Yes
	Over Voltage Protection	Yes
	Thermal Protection	Yes
	Short Circuit Protection	Yes
	Operating mode	Constant Current
	Photometric data
	Color temperature	3000K/4000K/6000K
	Luminious flux	2700/2850/3000
	Luminious efficacy	90/95/100
	Color rendering index (CRI)	>80
	Standard deviation of color matching (SDCM)	≤5 Step
	Beam angle	110°(±10°)



Product Dimmension	L-1200 X W-63 X H-80mm
Height	80mm
Product weight	3.2kg
Body material	Extruded Aluminium
Driver Housing color	White
Product color	white

Product Description

AREAS OF APPLICATION

Offices

Banks

Hospitality

Cafe & Restaurant

PRODUCT BENEFITS

High luminious efficacy

Energy saving upto 90%

Easy installation with fast connection

PRODUCT FEATURES

High efficiency 100 Lumen per watt

Glare free evenly Distributed

Long Life Span

Aluminium Extrusion housing with high efficient PC low glare diffuser
